CUSTOM MAGNETIC DATA CABLES
Custom 2-Pin Magnetic Data Cable, 1 A / 5 V – YT-MDC-035
SKU YT-MDC-035
Custom magnetic cable assemblies developed for charging plus defined data or signal transmission tasks.
Pin definition
Power, data, signal and ground assignments are confirmed with the device-side magnetic interface.
System verification
Charging, communication and mechanical reliability are verified with the target device and agreed test conditions.
VERIFIED SOURCE DATA
Product specifications
Values below are translated from the existing factory-reviewed product record. Final tolerances, test methods and acceptance criteria follow the project-approved drawing and specification.
| Yongtan Model | YT-MDC-035 |
|---|---|
| Pin Count | 2 |
| Working Stroke | 0.9 mm |
| Rated Current | 1 A |
| Rated Voltage | 5 V |
| Contact Resistance | 0.3MΩ max. |
| Insulation Resistance | 300V/DC 10MΩ min. |
| Spring Force | 80±15gf |
| Mechanical Life | 100000 cycles or more |
| Operating Temperature | -40°~85° |
PRODUCT DOCUMENTATION
Product images & engineering references
Open any image to view the original file. A drawing is displayed only when the supplied engineering archive links it to the same product and contains no model-label conflict; no drawing or dimension is generated from appearance alone.
