Answers for custom pogo pin and magnetic connection projects

A magnetic charging cable is designed primarily for power delivery. A magnetic data cable also carries defined data or signal paths, so pin assignment, conductor construction, shielding and system verification require additional review.

Projects can be reviewed for the input connector, magnetic-head shape, pin count and assignment, current, voltage, data or signal task, cable length and construction, ingress direction, magnetic force, color, logo and packaging.

The shape should be selected together with the available device space, industrial design, alignment direction, pin layout, sealing concept, assembly method and the way the user connects and releases the product.

Pins are assigned to power, ground, data, signal, detection or anti-misconnection tasks. The final count must also fit the magnetic-head space, contact layout and required creepage or clearance.

It can be evaluated for the project, but the answer depends on the contacts, pin allocation, wire gauge, contact resistance, temperature rise, mating condition and heat dissipation. Appearance alone cannot establish a safe current rating.

No. Magnetic force must balance stable contact, user operation and safe breakaway behavior. Device weight, support, mating direction and use conditions all influence the correct target.

Ingress protection can be evaluated, but the magnetic head, device receptacle, installation seal and assembled-device test condition must be considered together. A component result does not automatically establish the rating of the complete device.

Share the device application, drawings, available space, interface, pin count and assignment, current, voltage, data or signal requirements, cable length, ingress direction, magnetic-force target, test requirements and estimated quantity.

Yes. Standard-reference or customized samples can be evaluated. Quantity, cost, scope and lead time are confirmed after the available project information has been reviewed.

The products are custom project references rather than a universal retail catalog. Pricing depends on the model, specification, quantity, validation, tooling, documentation and packaging scope.

Depending on the product and application, checks may include ingress, salt spray, tensile force, cable swing or flex, continuity, contact resistance, voltage withstand, insulation, temperature rise, temperature and humidity.

Use the English inquiry form to attach a supported file, email bella@ytanpogo.com, or contact Bella through WhatsApp at +86 136 0265 2557.

A pogo pin is an individual spring-loaded contact. A pogo pin connector combines multiple contacts with a defined pitch, housing, array and mounting structure for integration into the device.

No. Images, SKUs, specifications and drawings are customer case references. Final dimensions, materials, plating, electrical performance, availability and validation conditions are confirmed for each new project.
