PRECISION SPRING CONTACTS
Custom SMT Pogo Pin – YT-PP-551
SKU YT-PP-551
Custom spring-loaded contacts for charging, signal, grounding, testing and compact device integration.
Electrical and plating
Current, voltage, contact resistance, force, travel, materials and plating are confirmed for each project.
Application validation
The final design is verified in the actual assembly and operating environment.
VERIFIED SOURCE DATA
Product specifications
Values below are translated from the existing factory-reviewed product record. Final tolerances, test methods and acceptance criteria follow the project-approved drawing and specification.
| Yongtan Model | YT-PP-551 |
|---|---|
| Full Stroke | 1.40 mm |
| Contact Resistance | 50 milliohm Max. |
| Mechanical Life | 100,000 ~1,000,000 cycles | 1,000,000 cycles | 100,000 cycles |
| Plunger Material | Brass Au over Ni |
| Barrel Material | Brass Au over Ni |
| Spring Material | SUS surface treatment |
| Plating | Gold,Silver,Palladium Nickel(customized) |
| Mounting Method | SMT |
